Multi Channel Rotary Fiber Optic Slip Ring 850nm 1550Nm Stainless Steel Housing

Ask Latest Price
Video Channel
Brand Name :CENO
Model Number :FCN0231G-67A
Certification :CE,RoHS,ISO9001,UL
Place of Origin :China
MOQ :1pcs
Price :Negotiable
Payment Terms :T/T,Paypal, Western Union
Supply Ability :500pcs per month
Delivery Time :1 week
Packaging Details :Carton/As request
Circuits :2-31 channels optional
Protection Grade :IP54
Working speed :0-400 rpm
Contact material :Precious metal
Housing material :Aluminium alloy
Working temperature :-20 ~ +60 °C
Fiber type :FC/PC/SMA
Wave length :850/1550 nm
Weight :1300 g
more
Contact Now

Add to Cart

Find Similar Videos
Industry Fiber Optic Rotary Joint Design Integrated Slip Ring With FORJ 00:18
Industry Fiber Optic Rotary Joint Design Integrated Slip Ring With FORJ
Low Temperature Integrate RF Rotary Joint Slip Ring With 1000M Ethernet Signal 00:48
Low Temperature Integrate RF Rotary Joint Slip Ring With 1000M Ethernet Signal
IP51 Integrated Slip Ring Combined Power Signal And Fiber Optic Rotary Joint 00:42
IP51 Integrated Slip Ring Combined Power Signal And Fiber Optic Rotary Joint
4 Channels Fiber Optical Rotary Joint With Integrated Power And 485 Signal 00:50
4 Channels Fiber Optical Rotary Joint With Integrated Power And 485 Signal
Multi - Channel Fiber Optical Rotary Joint IP54 38mm Wave Length 300rpm Speed 00:41
Multi - Channel Fiber Optical Rotary Joint IP54 38mm Wave Length 300rpm Speed
IP68 8 Channels Fiber Type SM FC-APC Fiber Optic Rotary Joints FORJs Slip Rings 01:26
IP68 8 Channels Fiber Type SM FC-APC Fiber Optic Rotary Joints FORJs Slip Rings
FC Connector IP65 50rpm SM MM Fiber Optic Rotary Joint 01:08
FC Connector IP65 50rpm SM MM Fiber Optic Rotary Joint
Low Temperature Capsule Slip Ring With HDMI RS422 Ethernet Signal 00:39
Low Temperature Capsule Slip Ring With HDMI RS422 Ethernet Signal
Industrial Through Hole 1000M Ethernet Signal Slip Rings For Automatic System 00:49
Industrial Through Hole 1000M Ethernet Signal Slip Rings For Automatic System
View Product Description

Multi-channel fiber opticl rotary joint 2-31 channels optional,wavelength 850/1550 nm,stainless steel housing material.it's widely used for medical OCT, medical equipment,packaging machine,inspection instrument,rotary tables etc.

CENO has focused on the rotary interface needs of the energy industries more than 10 years.The fiber optic rotary joints are recognized around the world for innovative performance and reliability in harsh marine environments.FCN0231G-67A with 2 channels to 31 channels fiber optional,IP grade upto IP65.We design for demanding conditions.Rigorous testing of every fiber optic rotary joint is performed in our own environmental testing chambers and the facilities of testing specialists.Standard features,such as connector interfaces that allow for easy replacement of damaged pigtails,are designed to minimize down time.

Specification

FCN0231G-67A Specification
Fiber channel 2-31 channels optional
Wavelength 850nm -1550nm (SM/MM)
Bandwidth +/- 50nm
Insertion loss <3.5dB
Pulling force ≤12N
Operating speed 0-400 rpm
Return loss ≥40dB
Weight 1300 g
Housing material Stainless steel
IP grade IP54
Vibration shock standard GJB150
Connector FC/PC/SMA

Features

  • Fiber channel upto 31

  • Wavelength 850-1550nm

  • Easy to integrate power

  • Maintenance free

Applications

  • Antenna system
  • Simulator tester
  • Offshore applications
  • Marine Winch

Optional

  • Circuits number
  • IP protection grade
  • Fiber optic type
  • Signal type & current rating
  • Wavelength

Outline drawing

Multi Channel Rotary Fiber Optic Slip Ring 850nm 1550Nm Stainless Steel Housing

Our Service

1. Reply inquiry in 24 hours.

2. Please kindly inform us which items you are interested & the reasonable price will be provided you upon receipt of your new inquiry ASAP.

3. Answer your question detailed.

4. Solved the problem with you during using our products.

5. Samples will be offered to you for our future cooperation.

Why with CENO

CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.

Multi Channel Rotary Fiber Optic Slip Ring 850nm 1550Nm Stainless Steel Housing

Certification

ISO9001,CE,RoHS,UL,Explosion-proof

Multi Channel Rotary Fiber Optic Slip Ring 850nm 1550Nm Stainless Steel Housing

CENO Advantage

Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.
